3PC Screwed Ends Ball Valve

Get a Price/Quote

MOQ : 1 Unit

3PC Screwed Ends Ball Valve Specification

Channels
2 Way

Pressure
PN16, PN25, Class 150, 1000 PSI

Caliber
Full Bore

Connection
Screwed Ends (BSP, NPT, BSPT)

Structure
3 Piece Design

Material
Stainless Steel (SS 304/316), Carbon Steel, Brass

Power
Manual

Media
Water, Oil, Gas, Air, Steam

Temperature of Media
-20C to 180C

Port Size
1/4 to 4 (DN8 to DN100)

Finish
Polished, Sandblasted

Application
Industrial, Chemical, Petrochemical, Water Treatment, Oil & Gas

Blowout Proof Stem
Yes

Fire Safe Design
Available on Request

End Connection Standard
BSP/BSPT/NPT

Operation
Lever Handle, Optional Actuator

Seat Material
PTFE, R-PTFE, TFM

Body Seal
PTFE Gasket

Locking Device
Available

Test Standard
API 598, BS 6755

Weight
Varies by size (refer datasheet)

Design Standard
ASME B16.34 / API 608

3PC Screwed Ends Ball Valve Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Units Per Month

Delivery Time
7 Days

Main Domestic Market
All India

3PC Screwed Ends Ball Valve About

PRODUCT - INVESTMENT CASTING CF8 - CF8M 3PC SCREWED ENDS FULL BORE BALL VALVE

BODY - ASTM A 351 Gr. CF8 - CF8M
BALL - ASTM A 351 Gr. CF8 - CF8M
STEM - AISI 304/AISI 316
SEAT & SEAL - PTFE
MFG. STD - BS 5351/API6D
INSP. & TEST - BS 6755/API598
LEVER - SS WITH PVC SLEEVE
ENDS - SCREWED TO BSP/SOCKETWELD

HYD.TEST PRESSURE -

BODY - 425 Psig(30Kg/Cm2)
SEAT - 300Psig(21Kg/Cm2)
SIZE RANGE - 15MM TO 80MM

Full Bore, 3 Piece Design for Maximum Flow

This ball valve features a full bore design, ensuring unobstructed fluid flow for applications across the industrial, chemical, petrochemical, water treatment, and oil & gas sectors. The three-piece construction enables convenient maintenance and seat replacement without removing the valve from the pipeline.

Versatile Seat and Body Sealing Materials

Equipped with PTFE, R-PTFE, or TFM seat materials, these valves offer outstanding chemical compatibility, durability, and temperature resistance from -20C to 180C. The PTFE gasket as body seal enhances leak tightness, making the valve suitable for a wide spectrum of fluids under varying pressures.

Reliable Safety and Mounting Features

Benefits include a blowout-proof stem for added safety, an optional fire-safe design, and the availability of a locking device for secure positioning. Manual lever operation is standard, but the valve can also be fitted with an actuator for remote or automatic control, accommodating a broad range of operating environments.

FAQ's of 3PC Screwed Ends Ball Valve:

Q: How should I select the appropriate seat material for the 3PC Screwed Ends Ball Valve?

A: The seat material should be chosen based on chemical compatibility with the media and the application's temperature range. PTFE and R-PTFE are suitable for most industrial chemicals and operate up to 180C, while TFM offers enhanced creep resistance in demanding environments.

Q: What is the typical process for installing and maintaining this type of ball valve?

A: Installation involves connecting the threaded ends (BSP, NPT, or BSPT) to system piping, ensuring proper alignment and tightening. For maintenance, the 3-piece body allows seat and seal replacement without removing the entire valve, minimizing downtime.

Q: Where can this ball valve be used effectively?

A: This valve is ideal for use in industrial, chemical, petrochemical, water treatment, and oil & gas sectors. Its versatility allows it to handle water, oil, gas, air, and steam, making it suitable for various fluid control applications.

Q: What are the operational benefits of the blowout-proof stem and optional locking device?

A: The blowout-proof stem enhances safety by preventing stem ejection under pressure, while the optional locking device ensures the valve remains securely in the desired open or closed position, helping avoid unintended operation.

Q: When is it advisable to request the fire-safe design option?

A: A fire-safe design should be requested when the valve is used in environments where fire risks are present, such as chemical or petrochemical plants, to ensure continued sealing performance and safety during fire exposure.

Q: What is the recommended usage for this valve concerning pressure and temperature ratings?

A: The valve is suitable for pressures up to PN16, PN25, Class 150, or 1000 PSI, and temperatures between -20C and 180C. Always consult the datasheet for specific limits based on valve size and material selection for safe operation.
