Quick Release Coupling

Introducing our high-performance Quick Release Coupling, a prime solution for your hydraulic and pneumatic connectivity needs. As an exporter, manufacturer, supplier, and trader with over 26 years of outstanding industry experience, we bring you the most gorgeous range of couplings, including Flat Face Coupling, Screw Coupling for Jacks, Hydraulic QRC Coupling, and Pneumatic QRC Coupling. Designed for seamless and swift connections, our Quick Release Coupling guarantees exceptional durability, leak-proof performance, and enhanced operational safety. These customizable beauties outperform traditional options with their user-friendly design, corrosion resistance, and unmatched reliability. Perfectly suited for a variety of industrial applications, these couplings are available in limited stock to ensure premium exclusivity and uncompromised quality. With supply ability across the domestic market of All India, we promise the ultimate convenience and accessibility. Each coupling is precision-engineered for smooth functionality, facilitating greater efficiency and effortless maintenance. Choose our Quick Release Coupling for outstanding performance, easy installation, and superior craftsmanship that stands the test of time. Order now to experience a product that combines premium quality with the best in industry innovation.

Flat Face Coupling

MOQ : 100 Units

  • Application
  • Hydraulic systems, Loading arms, Construction machines, Agricultural equipment, Industrial machinery, Earth moving equipment
  • Bore
  • 12 mm
  • Connection
  • Other, Push to connect, Threaded
  • Head Code
  • Other, Hexagonal
  • Inner Diameter
  • 12 mm
  • Material
  • Other, Carbon steel, Stainless steel, Brass
  • Outer Diameter
  • 34 mm
  • Sealing
  • Nitrile (NBR), Viton, PTFE O-ring
  • Shape
  • Other, Flat Face, Cylindrical
  • Standard
  • ISO 16028, DIN, SAE
  • Structure
  • Other, Flat face, Non-spill
  • Surface Treatment
  • Other, Zinc plated, Passivated, Anti-corrosion coating
  • Technique
  • Other, Precision machined
  • Thread
  • BSP, NPT, Metric
  • Torque
  • Hand tight

Screw Coupling for Jacks

MOQ : 100 Units

  • Application
  • Scaffolding Jacks Coupling
  • Bore
  • Threaded
  • Connection
  • Other, Threaded Coupling
  • Head Code
  • Round
  • Inner Diameter
  • 28.5 mm - 35 mm (as required)
  • Material
  • Other, Mild Steel/ Carbon Steel
  • Outer Diameter
  • 34 mm - 45 mm (as required)
  • Sealing
  • Metal to Metal
  • Shape
  • Other, Cylindrical
  • Standard
  • IS/BSCustom
  • Structure
  • Other, Sleeve Coupling
  • Surface Treatment
  • Other, Galvanized/ Zinc Plated
  • Technique
  • Other, Forged/ Machined
  • Thread
  • Metric/ BSW/ Custom
  • Torque
  • Up to 500 Nm (varies by size)

Hydraulic QRC Coupling

MOQ : 100 Units

  • Application
  • Hydraulic systems, pneumatic equipment, fluid transfer lines, agricultural machinery, industrial equipment
  • Bore
  • Standard and custom bore sizes available (typically 1/4 to 2)
  • Connection
  • Other, Quick release (push and pull locking mechanism)
  • Head Code
  • Other, Hex
  • Inner Diameter
  • As per model, typically from 6 mm to 50 mm
  • Material
  • Other, Carbon Steel, Stainless Steel, Brass
  • Max. Speed
  • Applicable for high-speed fluid transfer applications
  • Outer Diameter
  • As per model, typically from 14 mm to 60 mm
  • Sealing
  • Nitrile (NBR), Viton O-ring, leak-proof construction
  • Shape
  • Other, Straight, cylindrical body with knurled gripping surface
  • Standard
  • ISO 7241-A / ISO 7241-B, DIN, SAE standards compatible
  • Structure
  • Other, Plug and Socket assembly
  • Surface Treatment
  • Other, Zinc plated, Chrome plated, Corrosion resistant coating
  • Technique
  • Other, Precision machined
  • Thread
  • BSP, NPT, UNF, Metric threads available
  • Torque
  • Suitable for standard hydraulic line torque values

Pneumatic QRC Coupling

MOQ : 100 Units

  • Application
  • Quick connection and disconnection of pneumatic air lines and tools
  • Bore
  • Standard bore sizes available (customized on request)
  • Connection
  • Other, Threaded/Push type
  • Head Code
  • Other, Hex
  • Inner Diameter
  • 6 mm
  • Material
  • Other, Brass/Steel/Stainless steel
  • Max. Speed
  • Suitable for rapid coupling usage
  • Outer Diameter
  • 12 mm
  • Sealing
  • Nitrile rubber or Viton O-ring
  • Shape
  • Other, Straight/Hexagonal
  • Standard
  • ISO 6150/Equivalent
  • Structure
  • Other, Two part (male & female coupler)
  • Surface Treatment
  • Other, Zinc plated/Chrome plated
  • Technique
  • Other, Precision machined
  • Thread
  • BSP/NPT/Metric
  • Torque
  • Hand tight (not torque loaded)
